아래의 모든 사양은 마케팅 범위가 아닌 실제로 구축하고 테스트한 값입니다. 세 번째 열은 대서양에서 각 사양이 중요한 이유를 보여줍니다.
| Parameter | Specification | US & EU Localization Notes |
| Conductor | Tinned copper, Class 5/6 fine stranding | Solder-friendly for US contract manufacturers; resists vibration fatigue on rough EU road surfaces |
| Wire gauge | 10AWG–22AWG (5.26–0.33 mm²) | Dual-labeled: AWG for US drawings, mm² for EU documentation — no conversion errors between teams |
| Current rating | 40A continuous / 80A peak (4 mm² reference build) | Sized for US residential storage inverters and EU 48–72V light-EV controllers |
| Voltage rating | Up to 1,500V DC | Covers BESS string voltages on both continents |
| Operating temperature | -40°C to +125°C | From Minnesota cold starts to southern Spanish summer heat |
| Insulation | XLPE / silicone / LSZH halogen-free options | Halogen-free grades for EU REACH programs; flame-retardant grades aligned with US UL material requirements |
| Sealing | IP67 / IP68 optional | Built for rainy EU climates and outdoor US installations |
| Connectors | XT60, Anderson SB series, TE/Molex/JST equivalents, 2+6 pin | Drop-in equivalents of connectors you already source in the US and EU — no redesign needed |
| Testing | 100% continuity + hipot; bending, heat-chamber verification | Workmanship held to IPC/WHMA-A-620 Class 2 criteria |
| Compliance | UL-compliant materials, ISO 9001:2015, REACH/RoHS-ready | Document pack per shipment: CoC, RoHS report, REACH SVHC declaration |
| MOQ | From 100 pcs; sample evaluation supported | Pilot-run friendly for both startup and tier-1 buyers |
| Lead time | Samples 5–7 days; mass production 15–25 days | FOB HK, with JIT staging available for repeat orders |
